Airbag Launching Ship Shock Absorption Ship Launching Balloon
Description
Airbag launching not only saves costs but also supports sustainable shipyard practices. The reusable nature of the airbags and their low energy requirements reduce waste and operational expenses. This dual benefit of affordability and sustainability makes airbag launching a preferred choice for shipbuilders looking to optimize resources.
Specifications
| Item | Description |
| Place of Origin | China |
| Brand Name | Hongruntong Marine |
| Model Number | HM-ALS0195 |
| Material | Industrial-Grade Natural Rubber |
| Diameter | 0.5m-3.0m, or as Request |
| Length | 1.0m-28.0m, or as Request |
| Working Pressure | 0.05-0.25 mpa |
| Technics | High pressure, overall winding, explosion-proof |
| Use | ship launching and docking |
| Thickness | 5-13 ply |
| Standard | Conducted by ISO14409 and GB/T1590-2006 system. |
| Accessories | Q355/SS304/SS316, Pressure Gauge, Tee, Plug, Switch, Inflation Tube |
| Packaging | Inner-Plastic Bag; Outer-Standard Wooden Pallets. |
| Keywords | Airbag Launching Ship |
| Certificates | ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS |
| MOQ | 1 |
| OEM | Welcome |
| Diameter | Working Pressure | Working Height | Bearing Capacity |
| KN/m | Ton/m |
| D=1.0m | 0.14Mpa | 0.6m | 87.96 | 8.98 |
| 0.5m | 109.96 | 11.22 |
| 0.4m | 131.95 | 13.46 |
| D=1.2m | 0.12Mpa | 0.7m | 94.25 | 9.62 |
| 0.6m | 113.10 | 11.54 |
| 0.5m | 131.95 | 13.46 |
| 0.4m | 150.80 | 15.39 |
| D=1.5m | 0.10Mpa | 0.9m | 94.25 | 9.62 |
| 0.8m | 109.96 | 11.22 |
| 0.7m | 125.66 | 12.82 |
| 0.6m | 141.37 | 14.43 |
| 0.5m | 157.08 | 16.03 |
| D=1.8m | 0.09Mpa | 1.1m | 98.96 | 10.10 |
| 1.0m | 113.10 | 11.54 |
| 0.9m | 127.33 | 12.98 |
| 0.8m | 141.37 | 14.43 |
| 0.7m | 155.51 | 15.87 |
| 0.6m | 169.65 | 17.31 |
| D=2.0m | 0.08Mpa | 1.2m | 100.53 | 10.26 |
| 1.1m | 113.10 | 11.54 |
| 1.0m | 125.66 | 12.82 |
| 0.9m | 138.23 | 14.11 |
| 0.8m | 150.80 | 15.39 |
| 0.7m | 163.36 | 16.67 |
| 0.6m | 175.93 | 17.95 |
| * Other size can be produced follow client's requirements. |
Features
Sustainable Design
Supports environmentally responsible shipbuilding practices.
Shock Absorption
Reduces impact during launching, protecting the vessel.
Proven Track Record
Over 30 years of industry success in airbag manufacturing.
Ideal for Emergency Operations
Can be deployed quickly for rescue or repair scenarios.
Applications
● High speed ferry launching
● Submarine launching
● Sailboat launching
● Icebreaker launching
Advantages
Resilient Airbag Designs
Resistant to abrasion, chemicals, and extreme conditions.
Strong Industry Relationships
Partnerships with leading shipbuilding companies.
Local and International Recognition
Established reputation in the maritime industry.
Comprehensive Warranty
Peace of mind with reliable product guarantees.
FAQ
1. What is the delivery time for an airbag order?
It varies by location but is typically within weeks.
2. Can airbags be designed for oversized ships?
Yes, we specialize in custom solutions for large vessels.
3. Do airbags work in shallow waters?
Yes, they are suitable for shallow and deep waters alike.
4. How do airbags handle inclines or slopes?
They are designed to work efficiently on sloped terrains.
